Technics Parts for SL-1200/1210 MK2/MK5 Turntable


Start-Stop Button

33 RPM Button

45 RPM Button

Technics Lubricating Oil (Lube Oil for Turntable)

Replacement Ground Wire

Replacement Turntable RCA Cord

EP Record Adaptor

Sub-Weight

Counter Weight

Arm Rest

Arm Lift Lever

Replacement Foot

Power Switch Knob

Dust Cover Hinge Kit Assembly

Dust Cover Hinge

Turntable Dust Cover (without Hinge)

Replacement Pitch Control

Headshell Pro Series - Available in Silver, Black & Gold

Headshell Pro

Headshell Classic (INDUSTRY STANDARD)

Technics DJ SLIPMATS






Technics DJ SLIPMATS

SLIP-MAT FOR PROFESSIONAL DJs

* Made of special processing felt for DJs
* Made of anti static processing felt

Technics SH-DX1200 The Official DMC World Championship Mixer


Technics SH-DX1200 The Official DMC World Championship Mixer

The official DMC world championship mixer, the SH-DX1200, is stripped down to perfection and built to last. This mixer sports an ergonomically designed, long lasting optical cross fader.

specs
Colors available SH-DX1200K: Black
Fader Section with Digital Control No
3-Band Equalizers for Each Channel No
Optical Cross Fader Yes
Monitor Functions for Smooth Play Out Yes
Play Mode Functions for Club Sound-Space Control No
Versatile Effects Control No
Fader-Start Sync with Digital Turntable No
Input Sensitivity / Impedance Phono: 1.5 – 15mV / 47 ohms
Line, CD/Line: 100 – 1000mV / more than 10 kilo-ohms
AUX/Effector: 150mV / 47 ohms
Mic: 0.7mV / 1 kilo-ohm
Output Level/Impedance Line: 1V / 600 ohms
Monitor: 2V / 2.2 kilo-ohms (headphones open)
Headphones: 1.5V / 100 ohms (load 100 ohms)
Rec: 1V / 2.2 kilo-ohms
Maximum Output Level Line: 8V
Monitor: 8V (headphones open)
Headphones: 1.5V (100 ohms)
Rec: 8V
(Load 10 kilo-ohms except headphones)
Load Impedance Line: More than 600 ohms
Monitor: More than 10 kilo-ohms
Headphones: more than 47 ohms
Rec: More than 10 kilo-ohms
Residual Hum and Noise Less than 0.2mV
Frequency Response Phono: 30Hz – 15kHz (RIAA ±1dB)
Line: 10Hz – 70kHz (-3dB)
AUX/Effector: 10Hz – 100kHz (-3dB)
Mic: 100Hz – 15kHz (-3dB)
Tone Controls (12dB/oct) Low: +12dB, -24dB (63Hz)
High: +12dB, -24dB (10kHz)
Power Supply AC240V, 50Hz
Power Consumption 16W
Dimensions (H x W x D) 4″ x 10 1/4″ x 12″
Weight 7.72 lbs

Technics RP-DJ 1210 DJ Headphone


Technics RP-DJ 1210 DJ Headphone

The Technics RPDJ1210 headphones are one of the best items from the Technics range. The sound is high quality with bass that you can’t imagine. They are suitable for DJ’s for single side monitoring and the use of side is never been easier.

Made in Japan

Features:
# New improved bass response
# Convenient coiled cord
# High end exclusive for DJ monitoring cans
# Free style monitoring with swing arm system
# Reversible housing for single side monitoring
# Splash proof design for live activity
# Convenient foldable design with carrying pouch
# Max input capacity 1,500 mW for even the loudest DJing events
# 24K gold plated stereo plug
# Frequency response 8Hz – 30kHz
# Carrying pouch included

Technics RP-DJ 1200 DJ Headphone


Technics RP-DJ 1200 DJ Headphone

The classic, original Technics DJ headphones are back in stock, the RPDJ1200 has been infamous for its sound and build quality.

The tough build has made this headphone a classic amongst DJ’s with its fold out ear piece and comfortable padding its perfect for those long tough DJ sets. The cable is the other favourite feature of the RP DJ1200, its straight and extremely tough with a gold plated connector.

Made in Japan

Features

High quality sound
The RP-DJ1200 is designed to deliver clear, high-quality sound even at very high volumes.

High Input & Wide Frequency Range Driver
Driver units: 41mm (1 5/8in.) diameter. Frequency response: 8Hz – 30kHz.

Folding Swing Arms
The RP-DJ1200 can easily fold into multiple configurations for standard use, one-sided monitoring and storage.

More features
# Carrying pouch included

Technics RP-DH1200 DJ headphone


Technics RP-DH1200 DJ headphone

* 50mm Large Drive Unit
* High Max Input Capacity 3500mW
* Frequency Response 5Hz - 30kHz
* Foldable Design with Swing Arm System
* Detachable Coil-Cord
* Carrying Pouch Included

Technics professional DJ headphones with swivel mechanism, foldable headband and large driver

Technics RP series professional DJ headphones are built with pro club-use in mind. Best possible frequency response and design, specifically for DJ use, mean that these phones will stand the most rigorous of audio and durability tests in today's club environment.

These headphones also feature an Extra Bass System, with an XBS port which enhances lower frequency response. A Neodymium Magnet, which has 8 times stronger magnet power than ordinary ferrite magnets, realizes higher sensitivity and frequency response.

Headphone
Features
Operating Principle Closed-back, dynamic headphones
Drive Unit (diam. in mm) 50.0
Impedance (Ohm) / 1KHz 50.0
Sensitivity (dB/mW ) 107.0
Max Input (mW) 3500.0
Rated Input (mW) 200.0
Frequency Response (Hz - KHz) 5 - 30
Cord Length (m) 3
Single Side Cord yes
In-Cord Volume Control n/a
Weight (g) without cord 360.0
MiniPlug (diam. 3.5mm) yes
Plug Adaptor (diam. 6.3mm) yes
Plug Type 3,5mm Stereo Plug, Gold-plated
Magnet Type Neodym
Colour Silver

Technics-Panasonic RP-HTX7 Monitor Headphones







Technics-Panasonic RP-HTX7 Monitor Headphones

* Retro classic design
* Lightweight
* Single sided cord for comfortable wearing
* 40mm driver unit
* 1.2m short + 2m extension cord
* Frequency response 7Hz-22kHz

Retro style high quality monitor headphones with adjustable housing.

High quality Panasonic headphones in a classic retro style with adjustable housing. Featuring a neodymium magnet which has 8 times stronger magnet power than ordinary ferrite magnets, realising higher sensitivity and wide frequency response. The XBS port enhancer lowers the frequency response.

1.2m cord suits outdoor use, and an additional extension cable is suitable for home audio.

New 40mm driver unit with Neodymium magnet and C.C.A.W. voice coil reproduces powerful bass, and detailed clear treble.

Single sided cord and one side monitoring system improve wearing comfort.

Gold plated plugs are rustproof and ensure minimal contact loss (for both 3.5mm plug, and 6.3mm plug.

Headphone
Features
Drive Unit (diam. in mm) 40.0
Impedance (Ohm) / 1KHz 40.0
Sensitivity (dB/mW ) 99.0
Max Input (mW) 1000.0
Frequency Response (Hz - KHz) 7Hz - 22kHz
Cord Length (m) 1.2 + 2m / 3.9 + 6.6ft.
Weight (g) without cord 153.0
MiniPlug (diam. 3.5mm) yes
Plug Adaptor (diam. 6.3mm) yes
Plug Type 3.5mm Stereo Plug, Gold-plated
Magnet Type Neodym
Colour Blue / Cream / Pink / Black / Green / Red

Technics-Panasonic RP-DJ120 DJ Style Headphones




Technics-Panasonic RP-DJ120 DJ Style Headphones

* New driver unit adapted for clear High-Mid sound
* New color, white/sky blue/light pink and black
* Reversible housing for one-side monitoring
* Gold plated plug and plug adaptor
* Frequency response 14Hz-24kHz

Headphone
Features
Drive Unit (diam. in mm) 28.0
Impedance (Ohm) / 1KHz 24.0
Sensitivity (dB/mW ) 105.0
Max Input (mW) 1000.0
Frequency Response (Hz - KHz) 12Hz-25kHz
Cord Length (m) 2m
Weight (g) without cord 96.0
MiniPlug (diam. 3.5mm) yes
Plug Adaptor (diam. 6.3mm) yes
Plug Type Gold
Magnet Type Neodymium

Technics SL-1210MK5G / SL-1210MK5G GOLD.LTD DJ Turntable



Technics SL-1210MK5G / SL-1210MK5G GOLD.LTD DJ Turntable

* 0-8% / 0-16% Changeable Digital Pitch Control
* Oxygen Free Cabling
* Stylus Pressure Adjuster
* Long Life Blue LED Stylus Light
* 0.6 Anti Skate
* Adjustable Brake Speed

Turntable section
Type Quartz direct drive. Manual turntable
Drive method Direct drive
Motor Brushless DC motor
Turntable platter Aluminum diecast. Diameter 33.2 cm (13-5/64"). Mass 1.7 kg (3.74 lb.)
Turntable speeds 33 1/3 and 45 rpm
Variable range pitch ±8 %, ±16 % (two settings)
Starting torque 1.5 kg / cm
Build-up characteristics 0.7 sec. from standstill to 33 1/3 rpm
Braking system Electronic brake
Wow and flutter 0.01 % WRMS / 0.025% WRMS (JIS C5521) / ±0.035% peak (IEC 98A Weighted)
Rumble – 56 dB (IEC 98A, unweightet) / – 78 dB (IEC 98A, weightet)

Tonearm section
Type low mass tone-arm with gimbal suspension, S-shaped
Effective length 230 mm (9-1/16")
Arm height adjustment range 0-6 mm
Overhang 15 mm (19/32")
Effective mass 12 g (without cartridge)
Offset angle 22°
Friction Less than 7 mg (lateral, vertical)
Tracking error angle Within 2° 32' (at the outer groove of 30 cm (12") record) / Within 0° 32' (at the inner groove of 30 cm (12") record)
Stylus pressure adjustment range 0 - 4 g
Applicable cartridge weight range 3.5 - 13 g / 11 - 20.5 g (including headshell)
Headshell weight [g] 7.5

General
Power Supply AC 110 – 127 V/220 – 240 V, 50 Hz
Dimensions [mm]
Width 453.0
Height 172.0
Depth 355.0
Weight [kg] 11.7
Power Consumption [w] 15.0

Technics SL-1200MK5 / SL-1210MK5 DJ Turntable



Technics SL-1200MK5 / SL-1210MK5 DJ Turntable

* 0.6g Anti Skate
* Adjustable Brake Speed
* Long Life LED Stylus Light
* 0-8% Continuous Pitch Shift with Reset
* Silver / Black

The evolution of a Legend.

Technics SL series turntables have become legendary with over 3 million sets being produced and used by DJs and clubs the world over. SL-1200MK5 features the undisputedly accurate, reliable and durable Quartz Direct Drive Motor, with Aluminium Diecast cabinets and heavy rubber base for vibration damping.

SL-1200MK5 is got the same dependable construction as the famous and record selling SL1210MK2 with the addition of 0.6g Anti Skate.


Turntable section
Type Quartz direct drive. Manual turntable
Drive method Direct drive
Motor Brushless DC motor
Turntable platter Aluminum diecast. Diameter 33.2 cm (13-5/64"). Mass 1.7 kg (3.74 lb.)
Turntable speeds 33 1/3 and 45 rpm
Variable range pitch 0-8% with Centre Indent
Starting torque 1.5 kg / cm
Build-up characteristics 0.7 sec. from standstill to 33 1/3 rpm
Braking system Electronic brake
Wow and flutter 0.01 % WRMS / 0.025% WRMS (JIS C5521) / ±0.035% peak (IEC 98A Weighted)
Rumble –56 dB (IEC 98A Unweighted) / –78 dB (IEC 98A Weighted)

Tonearm section
Type Universal
Effective length 230 mm (9-1/16")
Arm height adjustment range 0-6 mm
Overhang 15 mm (19/32")
Effective mass 12 g (without cartridge)
Offset angle 22°
Friction Less than 7 mg (lateral, vertical)
Tracking error angle Within 2° 32' (at the outer groove of 30 cm (12") record) / Within 0° 32' (at the inner groove of 30 cm (12") record)
Stylus pressure adjustment range 0 - 4 g
Applicable cartridge weight range 3.5 - 13 g / 11 - 20.5 g (including headshell)
Headshell weight [g] 7.5

General
Power Supply ~110-120 / 220-240 V, 50 or 60 Hz
Dimensions [mm]
Width 453.0
Height 172.0
Depth 355.0
Weight [kg] 12.0
Power Consumption [w] 13.5

Adjustable Brake Speed accessed from just beneath the platter, continuous pitch shift with a reset control for 100% precision and finished off with a Long Life White LED Stylus Light. This turntable comes in Technics silver finish.

M-AUDIO Software

M-AUDIO Software

Product listings & Spec/Picture/Link :

http://www.m-audio.com/index.php?do=products.family&ID=software

01 Pro Tools M-Powered 8 M-Audio Compatible World Class Production Software
02 Producer FactoryValuable Collection of Plug-ins for Pro Tools LE and Pro Tools M-Powered
03 Producer Factory Pro Comprehensive Collection of Valuable Plug-ins for Pro Tools M-Powered
04 Hybrid High-Definition Synthesizer
05 Strike The Ultimate Virtual Drummer
06 Velvet Vintage Electric Pianos
07 Structure Professional Sampler Workstation
08 Transfuser The Ultimate Groove Creator
09 Eleven LE Hyper-Realistic Guitar Amp Emulations for Pro Tools Systems

M-AUDIO Monitors » Reference Monitors

M-AUDIO Monitors » Reference Monitors

Product listings & Spec/Picture/Link :

http://www.m-audio.com/index.php?do=products.family&ID=studiomonitors

01 Studiophile CX5 High-Resolution Active Studio Reference Monitor
02 Studiophile CX8 High-Resolution Active Studio Reference Monitor
03 Studiophile BX5a Deluxe 70-watt Bi-amplified Studio Reference Monitors
04 Studiophile BX8a Deluxe 130-watt Bi-amplified Studio Reference Monitors
05 Studiophile AV 20 Portable Desktop Speaker System
06 Studiophile AV 30 Compact Desktop Speaker System
07 Studiophile AV 40 Desktop Speaker System
08 SBX10 240-Watt Professional Active Subwoofer
09 M-Audio EX66 Reference Monitor Professional High-Resolution Active MTM Reference Monitor
10 Studiophile DSM1 High-Resolution DSP Reference Monitor with 6.5-Inch LF Driver
11 Studiophile DSM2 High-Resolution DSP Reference Monitor with 8-Inch LF Driver

M-AUDIO Preamps

M-AUDIO Preamps

Product listings & Spec/Picture/Link :

http://www.m-audio.com/index.php?do=products.family&ID=preamps

01 Audio Buddy Budget Microphone Preamp
02 DMP3 Dual Microphone/Instrument Preamp
03 Octane 8-channel Preamp and A/D Converter with ADAT Lightpipe

M-AUDIO Microphones

M-AUDIO Microphones

Product listings & Spec/Picture/Link :

http://www.m-audio.com/index.php?do=products.family&ID=microphones

01 Nova Affordable Large Capsule Cardioid Microphone
02 Pulsar II Small-Diaphragm Studio Condenser Microphone
03 Pulsar II Matched Pair Small-Diaphragm Studio Condenser Microphones
04 Aries Professional Condenser Vocal Microphone
05 Luna II Professional Large-Diaphragm Condenser Microphone
06 Solaris Large-Capsule Multi-Pattern Condenser Microphone
07 Sputnik Multi-Pattern Large Diaphragm Vacuum Tube Condenser Microphone

M-AUDIO Keyboards | Controllers » Audio Interface Keyboards

M-AUDIO Keyboards | Controllers » Audio Interface Keyboards

Product listings & Spec/Picture/Link :

http://www.m-audio.com/index.php?do=products.family&ID=audiointerfacekb

01 KeyStudio 49i Keyboard-based Music Production System
02 ProKeys Sono 61 61-Key Portable Digital Piano with USB Audio Interface
03 ProKeys Sono 88 88-Key Portable Digital Piano with USB Audio Interface

M-AUDIO Keyboards | Controllers » MIDI Keyboard Controllers

M-AUDIO Keyboards | Controllers » MIDI Keyboard Controllers

Product listings & Spec/Picture/Link :

http://www.m-audio.com/index.php?do=products.family&ID=USBkeyboardcontrollers

01 Oxygen 25 25-Key USB MIDI Controller
02 Oxygen 49 49-Key USB MIDI Controller
03 Oxygen 61 61-Key USB MIDI Controller
04 Axiom 25 Advanced 25-Key Semi-Weighted USB MIDI Controller
05 Axiom Pro 25 Advanced 25-Key USB MIDI Controller with HyperControl Technology
06 Axiom 49 Advanced 49-Key Semi-Weighted USB MIDI Controller
07 Axiom Pro 49 Advanced 49-Key USB MIDI Controller with HyperControl Technology
08 Axiom 61 Advanced 61-Key Semi-Weighted USB MIDI Controller
09 Axiom Pro 61 Advanced 61-Key USB MIDI Controller with HyperControl Technology
10 KeyRig 49 Easy-to-Use 49-Note USB Keyboard
11 Keystation 61es 61-Key Semi-Weighted USB MIDI Controller
12 Keystation 88es 88-Key Semi-Weighted USB MIDI Controller

M-AUDIO Trigger Finger Drum Pad Control Surface


M-AUDIO Trigger Finger Drum Pad Control Surface

Trigger Finger puts the power to program and perform expressive percussion and drum parts at your fingertips. Its 16 velocity-sensitive pads are perfect for playing the drum sounds in your favorite software, launching loops and samples, or even controlling video projections -- and applying pressure to the pads can generate any MIDI controller you wish. Trigger Finger also gives you 8 knobs and 4 faders that are freely assignable to MIDI parameters such as volume, pan, pitch, and effects. Pre-programmed maps for Reason, Live, GM Drum, XG Drum, iDrum, and more make setup a snap -- and full programmability lets you customize the unit to fit your needs. Settings are easy to store via 16 presets, and M-Audio's free Enigma librarian software for PC and Mac lets you create a collection of even more. A simple USB cable is all it takes to connect and power Trigger Finger with your computer. It's time to take full control of your drum programming -and Trigger Finger is the right tool for the job.

Features
16 velocity and pressure-sensitive pads

8 assignable knobs

4 assignable faders

Pre-programmed maps for Live, Reason, GM Drum, XG Drum, and iDrum

Velocity control including fixed velocity mode

Program/bank change capability

Powered via USB connection or optional DC power supply

16 MIDI presets

Programmable with free Enigma librarian software

3-digit LED display

Class compliant with Windows XP and Mac OS X

Includes free Ableton Live Lite 4 software
Technical Info
Size: 11 in. (w) x 10 in. (d) x 2 1/4 in. (h)
279.4mm (w) x 254mm (d) x 57.2mm (h)

Compatibility:
-- MME

-- DirectX

-- Core MIDI

Windows minimum system requirements:
-- Windows XP

-- Available USB Port

Mac minimum system requirements:
-- Mac OS X 10.2.8 or higher

-- Available USB Port

M-AUDIO Monitors » Headphones | Earphones

M-AUDIO Monitors » Headphones | Earphones

Product listings & Spec/Picture/Link :

http://www.m-audio.com/index.php?do=products.family&ID=Earphones

01 IE-10 Professional Reference Earphones
02 IE-20 XB High-Precision Professional Reference Earphones with Enhanced Bass
03 IE-30 High-Definition Professional Reference Earphones with Dual-Driver Technology
04 IE-40 High-Definition Professional Reference Earphones with Triple-Driver Technology
05 Studiophile Q40 Closed-Back Dynamic Headphones

M-AUDIO Handheld Recorders

M-AUDIO Handheld Recorders

Product listings & Spec/Picture/Link :

http://www.m-audio.com/index.php?do=products.family&ID=handheldRecorders

01 MicroTrack II Professional 2-Channel Mobile Digital Recorder
02 MicroTrack 10dB Pad Passive In-line 10dB Pad for the MicroTrack

M-AUDIO Audio | MIDI Interfaces » MIDI Interfaces

M-AUDIO Audio | MIDI Interfaces » MIDI Interfaces

Product listings & Spec/Picture/Link :

http://www.m-audio.com/index.php?do=products.family&ID=midiinterfaces

01 MIDISPORT 1x1 1-In/1-Out USB Bus-Powered MIDI Interface
02 MIDISPORT 2x2 2-In/2-Out USB MIDI Interface
03 MIDISPORT 4x4 4-In/4-Out USB Bus-Powered MIDI Interface
04 Uno 1-In/1-Out USB Bus-Powered MIDI Interface

M-AUDIO Audio | MIDI Interfaces » FireWire Audio Interfaces

M-AUDIO Audio | MIDI Interfaces » FireWire Audio Interfaces

Product listings & Spec/Picture/Link :

http://www.m-audio.com/index.php?do=products.family&ID=FWinterfaces

01 ProFire 2626 High-Definition 26-in/26-out FireWire Audio Interface with Octane Preamp
02 ProFire 610 High-Definition 6-in/10-out FireWire Audio Interface with Octane Preamp Technology
03 ProFire Lightbridge 34-in/36-out FireWire Lightpipe Interface
04 FireWire Solo FireWire Mobile Audio Interface for Songwriter/Guitarists

M-AUDIO Audio | MIDI Interfaces » USB Audio Interfaces

M-AUDIO Audio | MIDI Interfaces » USB Audio Interfaces

Product listings & Spec/Picture/Link :

http://www.m-audio.com/index.php?do=products.family&ID=USBinterfaces

01 Fast Track Record Guitar and Vocals on Your Computer
02 Fast Track Pro 4 x 4 Mobile USB Audio/MIDI Interface with Preamps
03 Fast Track Ultra High-speed 8 x 8 USB 2.0 Interface with MX Core DSP Technology
04 Fast Track Ultra 8R High-speed 8 x 8 USB 2.0 Interface with 8 Preamps and MX Core DSP
05 MobilePre USB USB Bus-Powered Preamp and Audio Interface
06 Transit Hi-Resolution Mobile Audio Interface

M-AUDIO Audio | MIDI Interfaces » PCI Audio Interfaces

M-AUDIO Audio | MIDI Interfaces » PCI Audio Interfaces

Product listings & Spec/Picture/Link :

http://www.m-audio.com/index.php?do=products.family&ID=PCIinterfaces

01 Delta 1010LT 10-In/10-Out PCI Virtual Studio
02 Delta 1010 10-In/10-Out PCI/Rack Digital Recording System with MIDI and Digital I/O
03 Delta 66 Professional 6-In/6-Out Audio Card with Digital I/O
04 Delta 44 Professional 4-In/4-Out Audio Card
05 Audiophile 2496 4-In/4-Out Audio Card with MIDI and Digital I/O
06 Audiophile 192 High-Definition 4-In/4-Out Audio Card with Digital I/O and MIDI

M-AUDIO Torq 1.5 Upgrade DJ Performance/Production Software


M-AUDIO Torq 1.5 Upgrade DJ Performance/Production Software

* Top Features
* Full Features

* - cue, beat-match and mix digital files > leave your cumbersome records and CDs safe at home
* - works instantly and seamlessly with compatible M-Audio hardware > no complex set-ups or conflicts
* - organizes digital audio files (including iTunes) into easily searchable database >instant access to your entire digital library
* - supports optional third-party VST effects > add your own signature sound
* - 16-cell tempo-synced sampler > trigger loops and samples on the fly
* - ReWire support > take your performance to the studio
* - transmits and receives MIDI beat clock >flexible synchronization with external devices
* - compatible with control vinyl/CDs >easily integrates with traditional DJ hardware

What is it

Torq is a fully equipped DJ software workstation that provides innovative tools and production power to set you apart from everyone else. In addition to essential cueing, beat-matching and mixing, Torq goes beyond all other DJ applications by offering a host of real-time creative options unavailable anywhere else. Unique features like built-in effects processing, ReWire support and a 16-cell sampler let you bring powerful studio processing to your live sets, as well as infuse your studio productions with live energy. Torq software is designed to work seamlessly with select M-Audio DJ hardware, forming a completely integrated system for rock-solid performance hour after hour. Torq 1.5 brings dynamic new additions like Tempo Anchors, Tempo Master, zPlane Elastique time stretching, send/receive MIDI clock, a new toolbar and more.

Learn more about Torq 1.5 DJ Software

Free 1.5 Upgrade for New Torq Customers
Customers who purchased and registered a Torq system on or after January 17, 2008 are eligible for a free upgrade to Torq 1.5 software.

Learn more about upgrading to Torq 1.5 DJ software

Note: Torq Conectiv or Torq Xponent hardware is required. The Torq 1.5 upgrade only applies to Torq software. It does not apply to Torq LE.

Get in Sync

Torq 1.5 takes your performance beyond simple beat-matching and crossfading between tracks. Tempo Anchors allow you to set the phase grid exactly on the beats of a song—even if the song changes tempo. Tempo Anchors make it possible for Torq to remove tempo variations from songs so you can easily blend old styles and new. For example, if you have an old ‘70s funk song that was recorded without a click, Tempo Anchors enable you to perfectly match that song with the steady beat of today’s computer-driven productions. You can also assign a track you’re spinning to serve as the Tempo Master for everything in Torq, so looped samples and other tempo-based features will automatically match the natural tempo changes in the song. These new features are enhanced by the addition of the zplane élastique time stretching algorithm, a time compression/expansion tool that performs extreme audio warping with exceptional precision and sonic quality—allowing you to keep your entire mix perfectly in key.

Audio Production Centerpiece

On stage and in the studio, Torq 1.5 provides the ideal centerpiece for your audio production setup. Want to hook up your outboard gear? Torq can send and receive MIDI beat clock, allowing total synchronization with drum machines, effects boxes and other computers. Multiple DJs can now connect with each other and share the same tempo across systems—improving collaboration between artists.

Enhanced User Interface

Torq 1.5 software incorporates several highly anticipated new features that improve the user interface and provide new creative options. The Hide Mixer option conserves screen space by removing the mixer from the user interface and expanding the file browser window. The Browser Preview function lets you preview songs in your headphones before loading them into a deck. New file list categories such as “Year” and “Label” help with song organization—you can even hide and rearrange categories for improved searching through your database. Torq 1.5 also displays a warning message if you are exiting the program or loading a song onto a deck that’s already playing—preventing accidental set interruption during a live performance.

In addition, many of Torq’s preferences have been duplicated as small buttons in the redesigned toolbar. Commonly used features like External Control and AMPutate mode can now be enabled without opening the Preferences dialog. Sync mode, Schaffel mode and the new Skip Protection feature can also be changed on the fly. You can trigger all of these buttons with a compatible MIDI controller like M-Audio’s Oxygen 8 v2 or Trigger Finger.

Never Miss a Beat

Torq 1.5 also includes new features designed to enhance the mixing process and give you complete control over your set. Skip Protection for external vinyl control keeps the music playing—even if the needle briefly jumps or skips off the record. True Key Lock keeps the pitch constant when you change speed using external turntable controls or the scratch wheels on Torq Xponent. The new Auto Gain feature compensates for volume differences in songs—smoothing out transitions between tracks with different levels. And the MIDI Soft Takeover feature prevents parameter jumps when using external controllers.

Torq 1.5 also includes a new beat-detection algorithm that analyzes tracks according to Musical Style Preferences. You can select from a long list of styles before analyzing songs—improving the reliability of results. If a song is analyzed improperly, simply change the musical style and re-analyze the track.

Advanced Effects Processing

Torq revolutionized digital DJ performance and production by combining DJ software essentials with a broad assortment of cutting-edge effects. Torq 1.5 takes you even further with new features that improve effects processing and inspire creativity. The built-in effects can now be formed into Effects Chains, allowing more creative options than ever before. For example, you can take the output of a Delay and feed it into a Dual Filter and Reverb before mixing it back into the main outputs (great for dub-style swooshy delays).

Torq 1.5 also supports VST Tempo so external effects can be synchronized to the playing track. The innovative Snapshot feature now includes a powerful Swap function—allowing you to mirror your settings between decks. These advanced features help you create your own style, blurring the line between live DJ performance and advanced music production.

Stay in the Loop

Torq 1.5 stands apart from other digital DJ solutions by delivering advanced looping tools for remixing and mashing up tracks on the fly. The new Pre-Loop feature allows you to loop a section of audio you just passed—using the QuickLoop buttons to capture loops ending at the current position. Smart Mode ensures that you capture loops of musical size. When the Quantize feature is activated, new Loops and Cue points will be added at the nearest 16th note.

Torq’s QuickLoop buttons also have a new selectable behavior called Direct Mode, which mimics the behavior of DJ CD player loop buttons. Once a loop is created, the QuickLoop buttons become divisors of the loop length—pressing 2 will halve the current loop, while pressing 1 will return it to its original length.

Easier than Ever

A host of other innovative tools streamline the creative process and improve the user interface. For example, you can clear all effects by holding the shift key and clicking Bypass. It’s also easy to unload tracks from a deck—just hold shift and press either F1 or F2. When beat-juggling between decks, Cue Points added to one track are immediately reflected in the other. And when using the browser in max view, you can drag and drop tracks onto the tiny decks located at the top of the screen—without returning to regular view first. With all of these enhancements, Torq 1.5 is more powerful and easier to use than ever before.

M-AUDIO Torq Control Vinyl Control Vinyl Disk for Torq


M-AUDIO Torq Control Vinyl Control Vinyl Disk for Torq

* Top Features

* - ultra-fast response > behaves just like real vinyl
* - bi-directional positioning > allows for advanced scratching and beat-juggling techniques
* - heavy-duty construction > built to handle long hours of use
* - available in black, red, clear and ghost > customize your rig

What is it

Torq Control Vinyl disk allows you to control audio files in Torq with the same feel and response as real vinyl records. Simply connect a turntable to a suitable audio interface like M-Audio Conectiv, enable external control in Torq, and you’ll be able to cue and scratch your music just as if you were using the original records. With incredibly fast response, Torq Control Vinyl disks let you use even the most intricate scratching techniques, and bi-directional positioning ensures that Torq precisely tracks the vinyl for perfect beat-juggling. Disks are sold individually.

M-AUDIO Torq Control CD Control CD for Torq


M-AUDIO Torq Control CD Control CD for Torq

* Top Features

* - ultra fast response > behaves just like a standard CD
* - bi-directional positioning > allows for advanced scratching and beat-juggling techniques

What is it

Torq Control CD allows you to manipulate audio files in Torq using your favorite DJ CD player. Simply connect your player to a suitable audio interface, enable external control in Torq, and you’ll be able to cue and scratch your music just as if you were using the original CDs. Super-fast response allows for even the most intricate scratching techniques, and bi-directional positioning ensures that Torq precisely tracks the CD for easy beat-juggling. Control CDs are sold individually.

M-AUDIO Torq Xponent - Advanced DJ Performance/Production System


M-AUDIO Torq Xponent - Advanced DJ Performance/Production System

Top Features
integrated hardware/software DJ system > easy setup and stability
includes Torq 1.5 software > professional performance and production
includes Xponent hardware > integrated DJ-style control surface and audio interface
full-size, professional-grade controllers > durable, analog-feel tactile control
hardware controls pre-mapped to corresponding parameters in Torq > works instantly

The professional-grade Torq® Xponent® system seamlessly integrates high- performance DJ software with a fully functional hands-on controller, representing a new era in digital DJ performance and production. The Xponent hardware combines the features of a two-channel DJ mixer with CDJ-style tactile controls, letting you cue, mix and manipulate digital files without touching the host computer. In addition to the essentials, M-Audio® Torq 1.5 software delivers a variety of real-time creative tools to take your sets beyond the ordinary—and the Xponent hardware control surface puts all that power right at your fingertips. This integrated solution opens the door to new techniques that are simply impossible with traditional DJ setups.

Rock-Solid Professional DJ Hardware

The Torq Xponent hardware/software system delivers everything a professional DJ needs to perform with a computer. Xponent is both an advanced MIDI control surface for Torq software and a four-output USB audio interface that includes two stereo RCA outputs and a standard ¼'' headphone output for cueing. Every control on Xponent boasts the same rock-solid construction and rugged feel as traditional DJ hardware. So if you’re ready to make the leap to the world of software-based DJing, you’ll feel right at home with Xponent.

Get Inside the Mix

Torq 1.5 DJ software makes it easy to go beyond basic beat matching and crossfading between tracks. With a 16-cell, tempo-synced sampler, easy looping capabilities and multiple cue points, you can chop up a song—on the fly—and reorder, remix and extend any section you want, all while staying perfectly in time. The QuickScratch feature lets you instantly scratch with any two loaded samples. Tempo Anchors remove tempo variations from your tracks—or cause other songs to adopt the tempo changes—making mash-ups and live remixes a breeze. Tempo Master synchronizes all tracks, samples and effects within Torq, while MIDI clock transmits tempo information to outboard hardware and other computers so you can collaborate with friends. And if you also want to produce, Torq is ReWire-compatible with Pro Tools® M-Powered™ software and other popular applications.

Advanced Effects Processing

Torq 1.5 gives you 10 essential effects right out of the box for dynamic manipulation of your tracks. Imagine the possibilities of stacking multiple distortion, filter, repeat, chorus or bit-reduction effects while mixing between songs. You can turn any track into your own original creation—and even record it on the spot with the integrated performance recorder. Torq also allows you to create recallable snapshots of your favorite EQ, effect and mixer settings, and even supports the vast world of third-party VST effects plug-ins.

Dynamic Control Over Torq 1.5 Software

The best DJ tools allow you to get your hands on your music—from cueing to beat matching to scratching. M-Audio designed the Xponent control surface with full-size, DJ CD-player-style controls so you can get into the music and engage the crowd during each moment of your set. Xponent features 64 assignable backlit buttons (including Play, Cue, Seek, Loop, Key and Sync controls), two volume sliders, eight assignable knobs for effect control and two 100mm pitch sliders. The built-in touchpad/assignable X/Y controller allows you to control your mouse or the effects in Torq, so you never have to take your hands off the unit in the middle of a performance.

Made to Work Together

Torq 1.5 DJ software for Mac and PC automatically configures itself to work with Xponent—every hardware control is pre-mapped to its corresponding function in Torq. It’s easy to get up and running with Xponent because all of the hardware controls are located exactly where you’d expect them to be. The transition into digital DJing couldn’t be simpler.

Plays Well with Others

In addition to VST compatibility, Torq 1.5 software can interface with any ReWire-compatible host application. You can easily route the output of Torq to a program like Pro Tools M-Powered and explore even more performance, production and sound design possibilities. When ReWired to a host application, the tempo of Torq automatically locks to the current session tempo, so you never have to worry about syncing playback between Torq and your preferred DAW. In addition, the Xponent control surface can be MIDI-mapped to other digital audio workstation software including Ableton Live.

M-AUDIO X-Session Pro - USB MIDI DJ Mixer Controller


M-AUDIO X-Session Pro - USB MIDI DJ Mixer Controller

Top Features
USB MIDI controller with DJ mixer-inspired layout > perform using a single interface
27 MIDI controllers > tactile control of DJ applications, soft synths and DAWs
works with any software that supports MIDI Learn > use on stage and in the studio
class-compliant under Mac OS X, Windows XP, & Vista (32 bit) > no drivers, no complicated set-ups
powered via USB > goes everywhere your computer goes

The X-Session Pro USB MIDI controller is the easiest way to bring traditional DJ mixer-style control to the world of computer DJing and live performance. With a single USB connection, you get dedicated tactile controls for volume, pitch, EQ, cueing, transport and a crossfader. As a class-compliant USB MIDI controller, you can use it to control Torq LE DJ software, as well as the full version of Torq, Ableton Live, Traktor DJ Studio or any application that supports MIDI Learn. Start bringing DJ-inspired crossfades and filter sweeps into your live performances and studio productions right away.

Built to Rock
Today’s powerful laptop computers have brought near limitless options to DJs and performing electronic musicians. But the combination of a mouse and keyboard is not the most natural or musical interface for live performance. The X-Session Pro fuses the standard controls of a two-channel DJ mixer with the transport and pitch controls of a turntable or DJ CD player, enabling you to control everything from a single interface. The mixer controls allow you to adjust level, cueing, EQ and effects, plus make smooth crossfades—while the integrated transport and pitch controls allow you start, stop and beat-match digital files within software applications.

Wheels of Virtual Steel
The available Torq LE software (free download) organizes everything you need to DJ into a single, easy-to-use workspace. Two virtual decks let you load, cue and play back digital files—and will even automatically beat-match the files in an instant. And just like a traditional DJ setup, Torq LE includes an integrated two-channel mixer with three-band EQ, level controls, headphone cueing, a crossfader and three effects.

Plays Well with Others
The X-Session Pro brings DJ mixer-style tactile control to any software that supports MIDI Learn. The unit is a class-compliant MIDI device under Mac OS X and Windows XP, so you’ll never need extra drivers to make it interface with your favorite DJ applications, soft synths or DAWs—from Torq LE and Torq to Ableton Live, Pro Tools M-Powered and more. For example, you can easily assign the crossfader on the X-Session Pro to the crossfader within Ableton Live and add a new dynamic to your live performances or studio work. With a digital DJ application like Traktor, you can assign the various level, EQ and crossfader controls to the X-Session Pro. The possibilities are virtually endless.

* Driver installation on Windows XP required for multi-client operation

M-AUDIO Torq Conectiv Vinyl/CD Pack - DJ Performance/Production System with Control Vinyl and CD


M-AUDIO Torq Conectiv Vinyl/CD Pack - DJ Performance/Production System with Control Vinyl and CD

Top Features
includes Torq DJ software > instantly turn any Mac or PC into a powerful DJ rig
includes Conectiv 4 x 4 USB audio interface with 16-bit/48kHz fidelity > CD quality and beyond
4 RCA inputs configurable for line-level or phono signals > connects to all standard DJ mixers, turntables and CD players
supports MP3, AIFF, WAV, WMA and AAC files > cue, beat-match and mix standard digital audio files
use as a self-contained digital system, multi-effects processor or slave from included Control CDs/vinyl > totally flexible
hosts standard VST effects > powerful, expandable digital processing

Torq Conectiv—including the revolutionary Torq DJ software and Conectiv bus-powered 4 x 4 USB audio interface—is the breakthrough hardware/software system designed for DJs who perform and produce tracks with a laptop. Torq Conectiv delivers high-fidelity audio, all the right kinds of I/O (including dual phono preamps), and the ability to mix, beat-match and cue digital files with ease. Use it as a completely digital solution or process your vinyl and CDs on the fly. You can also create a hybrid digital/vinyl DJ rig with specially encoded Torq Control CDs and Torq Control Vinyl disks (both included). Torq supports popular file formats such as MP3, WAV, WMA and AAC files and is configured to automatically work with Conectiv right out of the box. And unlike most digital DJ systems, the Conectiv interface works with other third-party software as well.

Start Spinning Tonight

Torq Conectiv instantly turns any compatible Mac or PC into a powerful DJ rig—no configuration issues or prep work. That’s because M-Audio’s SynchroScience design group created the included Torq software and Conectiv interface to work seamlessly together right from the start. Just plug in your Conectiv interface, fire up Torq, and get down to business.

The Best of All Worlds

Torq gives you everything you need to DJ in a single, easy-to-use workspace. Torq includes an integrated two-channel mixer with three-band EQs, level controls, headphone cueing and a crossfader, just like a traditional DJ setup. Then the power of digital DJing kicks in. The program has two virtual decks where you can load, cue and mix digital files—including MP3, AIFF, WAV, WMA and AAC—and it will even automatically beat-match the files the instant you load them. Torq also organizes all of your digital files into an easily searchable database, letting you pull up the perfect track or change up your set in an instant. You can even access your entire iTunes library through Torq, so you can truly have all of your music at your fingertips.

Conectiv

The Conectiv USB interface delivers world-class M-Audio technology, outfitting your digital DJ rig with two pairs of RCA stereo inputs and outputs, microphone input and phono preamps. Two large knobs allow you to seamlessly mix between the incoming audio from a turntable or CD player and the output of a connected Mac or PC. Conectiv also includes standard DJ cueing capabilities, so you can listen to any track in your headphones before sending it out to the house system. And with a maximum output level of +2dBV, Conectiv gives you enough volume to go toe-to-toe with any DJ hardware on the market.

Universal Compatibility

While Torq and Conectiv are designed to work seamlessly together, Conectiv is also compatible with any Mac or PC software using CoreAudio and ASIO drivers—delivering low-latency performance as a recording interface for DAWs like Ableton Live, Logic, Cubase, Digital Performer and more. Of course, it’s also compatible with Pro Tools M-Powered 7.3 or later as your entrance into the world of industry-standard recording.

The Ultimate DJ Effects Unit

Torq supports the vast world of third-party VST effects plug-ins and allows you to create recallable snapshots of your favorite EQ, effect and mixer settings. You even get 10 exciting built-in effects right out of the box. Beyond using these effects on your digital files, you can use Torq Conectiv to turn a laptop into the most versatile DJ effects unit ever conceived for your vinyl and CDs. Imagine the possibilities of stacking multiple distortion, EQ, reverb, chorus or bit reduction effects and using the knobs on Conectiv to blend the dry and processed signals.

Live Remix Machine

With Torq, you’re never limited to just basic beat-matching and crossfading between tracks. With a 16-cell, tempo-synced sampler, easy looping capabilities and multiple cue points, you can chop up a song—on the fly—and reorder, remix and extend any section you want, all while staying perfectly in time. The QuickScratch feature even lets you instantly scratch with any two loaded samples. With the option of adding multiple effects, you can turn a song into a completely original piece of music and even record it on the spot with the integrated performance recorder. And for the DAW-savvy DJ, you can route the output of Torq to any ReWire-compatible host application like Pro Tools M-Powered 7.3 or later and share synchronization information between the programs.

Take Control

Torq lets you work the way you want to work. Rather than limiting you to DJing with just a mouse, Torq can also be controlled via keyboard or MIDI controller—like the X-Session Pro or Oxygen 8 v2. And with a compatible audio interface like the M-Audio Conectiv and M-Audio’s specially encoded Torq Control CDs or Torq Control Vinyl disks (both included), you can control digital files loaded in Torq with the feel of a traditional DJ setup. Torq includes multiple operating modes that can make playback behave like a traditional turntable or a DJ CD player—and there is even a hybrid mode that blends the strengths of both vinyl and CD-style control.

M-AUDIO Torq Conectiv - DJ Performance/Production System


M-AUDIO Torq Conectiv - DJ Performance/Production System

Top Features
integrated digital DJing and multi-effects processing system > easy setup and stability
includes Torq 1.5 software > professional performance and production
Conectiv audio interface > connect turntables or DJ CD players to control digital files
includes 10 built-in effects and support for VSTs > add a new dimension to your style
precise time stretching and Tempo Anchors > stay in sync even if the song changes tempo

As advancements in digital technology continue to propel the evolution of the DJ, only one computer-based program provides the creative tools and production power to set you apart from everyone else. In addition to essential cueing, beat matching and mixing, M-Audio® Torq® 1.5 software delivers a host of real-time creative tools to take your sets beyond the ordinary. The program combines exceptional vinyl/CD emulation with a host of progressive features such as built-in effects, multiple sampler options, advanced time-stretching and more. Just hook your turntables or DJ CD players into the Conectiv® audio interface and start exploring the endless creative possibilities. You can go completely digital or process your vinyl and CDs on the fly. Torq software is designed to work seamlessly with the Conectiv interface for easy setup and solid performance.

Torq 1.5 DJ Software

Torq 1.5 software delivers everything you need to DJ in a single, easy-to-use workspace. The program features an integrated two-channel mixer with three-band EQs, level controls, headphone cueing and a crossfader—just like a traditional DJ setup. Then the power of digital DJing kicks in. Torq software's two virtual decks allow you to load, cue and mix digital files—plus automatically beat match tracks with the push of a button. Torq also organizes all of your files into an easily searchable database, letting you pull up the perfect song or change up your set in an instant. Torq even gives you access to your entire iTunes library—literally putting all your music at your fingertips.

Get Inside the Mix

Torq software makes it easy to go beyond basic beat matching and crossfading between tracks. With a 16-cell, tempo-synced sampler, easy looping capabilities and multiple cue points, you can chop up a song—on the fly—and reorder, remix and extend any section you want, all while staying perfectly in time. The QuickScratch feature lets you instantly scratch with any two loaded samples. Tempo Anchors remove tempo variations from your tracks—or cause other songs to adopt the tempo changes—making mash-ups and live remixes a breeze. Tempo Master synchronizes all tracks, samples and effects within Torq, while MIDI clock transmits tempo information to outboard hardware and other computers so you can collaborate with friends. And if you also want to produce, Torq is ReWire-compatible with Pro Tools® M-Powered™ software and other popular applications.

Advanced Effects Processing

Torq 1.5 software gives you 10 essential effects right out of the box for dynamic manipulation of your tracks. Imagine the possibilities of stacking multiple distortion, filter, repeat, chorus or bit-reduction effects while mixing between songs. You can turn any track into your own original creation—and even record it on the spot with the integrated performance recorder. Torq also allows you to create recallable snapshots of your favorite EQ, effect and mixer settings, and even supports the vast world of third-party VST effects plug-ins.

Conectiv

The Torq Conectiv USB interface delivers world-class M-Audio technology, outfitting your digital DJ rig with two pairs of RCA stereo inputs and outputs, phono preamps and a microphone input. Two large knobs allow you to seamlessly mix between the incoming analog audio from a turntable or CD player and the digital output of a connected Mac or PC. Conectiv also includes standard DJ cueing capabilities, so you can listen to any track in your headphones before sending it out to the house system. And with a maximum output level of +10dBV, Conectiv gives you enough volume to go toe-to-toe with any DJ hardware on the market.

Traditional Feel

The included Torq Control Vinyl records and Torq Control CDs allow you to manipulate digital audio files with the same feel and response as a traditional DJ setup. Simply connect your turntables or DJ CD players to Conectiv, enable external control in Torq, and you'll be able to cue and scratch your music just as if you were using the original records or CDs. Extremely low latency and super-fast response allow for battle-style scratching techniques and easy beat juggling. Torq also includes multiple operating modes that can make playback behave like a traditional turntable or a DJ CD player—and there is even a hybrid mode that blends the strengths of both vinyl and CD-style control.

Take Control

Torq lets you work the way you want. In addition to mouse control, Torq can be operated using a QWERTY keyboard or MIDI controller like the M-Audio Oxygen 8 v2 or Trigger Finger. For instance, you could control the Torq software effects with the Trigger Finger sliders, while reserving the pads for snapshot settings that allow you to instantly switch between virtual mixer setups.

Universal Compatibility

While Torq and Conectiv are designed to work together seamlessly, Conectiv is also compatible with any Mac or PC software using CoreAudio and ASIO drivers—delivering low-latency performance as a recording interface for DAWs like Ableton Live, Logic, Cubase, Digital Performer and more. Of course, it's also compatible with Pro Tools M-Powered software as your entrance into the world of industry-standard recording.
