- Works with Serato DJ Pro & rekordbox
- Onboard Stem Control
- 16 Multicolored Performance Pads
- Dual 8" Jog Wheels
- 2-Channel Mixer with Built-In Sound Card
- Deck Select Button for Use with 4 Decks
- Combo XLR-1/4" + 1/4" Mic Inputs
- 2 USB-C Host Inputs
- Includes Serato Pitch 'n Time Expansion
- Includes USB-C Power Adapter and Cables
Engage with the latest Stem technology with the Pioneer DJ DDJ-REV5, a next-generation controller that works with Serato DJ Pro and rekordbox straight out of the box. The REV5 is a 2-channel controller that offers an authentic scratch experience with innovative features such as large 8.1" jog wheels, MAGVEL FADER, dedicated buttons for Stems control, the first-ever Auto BPM Transition, and Piano Play Mode.
The pitch sliders are located at the top of the controller, mimicking the popular "Battle-Style" setup used with scratch DJs on turntables. The rear panel provides a host of connections including XLR and RCA master outputs, a pair of 1/4" booth outputs, two microphone inputs, a stereo RCA aux input and two headphone outputs (1/4" and 3.5mm). The DDJ-REV5 includes a USB power adapter, a USB-C power cable, a USB-C data cable, and a Serato DJ Pro Pitch 'n Time DJ voucher.
The large jog wheels are responsive, reliable, and easy to operate—with a feel just like those on classic CDJ units—and they each include a display with playhead position, so you'll always know where you are in the track. You can also customize the Jog Feel to find your perfect jog wheel weight. The MAGVEL FADER is slick, robust, and ready to translate every tiny movement you make, so you can scratch with precision.
The long tempo sliders on the DDJ-REV5 run horizontally above the deck sections while the Performance Pads and Lever FX are placed in the mixer section for dynamic performances, emulating the PLX Series deck + DJM-S Series mixer setups loved by open-format DJs around the world. Thanks to the proximity of the pads, levers, and faders you can fuse scratching with pad play and effects.
Easily make live mashups and remixes using the Stems buttons on the DDJ-REV5. Your tracks will be split into Stems within the software—vocals, melody, bass, and drums in Serato DJ Pro, or vocal, drums, and inst (other instruments, including bass and synths) in rekordbox—which you can play separately.
- Stems Mute/Solo: solo or mute the different Stems to create your own mashups on the fly
- Stems Separate: isolate different Stems of a track on separate decks to make live remixes
- Stems Level: use the EQ knobs to adjust the volume for separate Stems
You can use the different Stems in combination with Deck Move, so it's easy to make and control multiple live mashups and remixes at once.
Mixing between musical genres with vastly different tempos is easy with the new Auto BPM Transition. Choose a number of bars for the transition and, when you press the button, the playing track will gradually change tempo to match the one loaded to the other deck, so you can seamlessly mix or drop in the new track. You can also set Stems, Auto Loop, and Key Lock control to be applied during the transition.
Just like Pitch Play, you can use the 16 Performance Pads to trigger a cue point in different semitones. But, with the new Piano Play mode, pitch changes are arranged, so the pads form a piano keyboard, with the "white" keys on the bottom row and the "black" ones at the top. Choose from 3 scales and, even if you have no knowledge of musical theory or scales, you'll find it easy to play a tune.
You can use the DDJ-REV5 as the center of a larger setup thanks to its wide variety of inputs and outputs, including an XLR master out that's perfect for use in professional environments. There are 2 USB Type-C ports for PC/Mac too, making it easy to swap between DJs with a simple flick of a switch on the controller.
Choose your favorite software and start DJing right away. You can simply plug the DDJ-REV5 into a PC/Mac running the latest version of Serato DJ Pro or rekordbox to use either application for free—you don't need a license key or subscription. A voucher for the Serato Pitch 'n Time DJ expansion pack is also included.
- USB Type-C: connect your PC/Mac directly to the controller's USB Type-C terminal with a single cable
- Performance pads: hit the 8 backlit rubber performance pads to trigger Hot Cues, Pad FX, Beat Jump, and the sampler
- Pitch 'n Time DJ: a voucher for the Serato Pitch &'n Time DJ expansion pack is included, which enables key shifting and key syncing with perfect audio quality
- Firmware Update Manager: you'll be automatically notified when firmware updates become available
Configuration | Dual-Deck |
Number of Channels | 2 x Stereo |
Platter/Jog Wheel | 2 x 8.1" / 20.6 cm Touch-Sensitive |
Motorized Platters | No |
Faders | 2 x Channel Level 1 x Crossfader 2 x Tempo/Pitch |
Sample Pads | 8 x Assignable per Deck (Backlit) |
EQ | 2 x Channel EQ: Hi Mid Low |
Performance Controls | BPM Counter, Beat Sync, Cues, EQ, Echo, FX, High-Pass Filter, Key Lock, Loop Points, Low-Pass Filter, MIDI Control, Master Tempo, Pitch Control, Sampler, Scratch, Search, Transport Controls, Vinyl Mode |
Sample Rates | 48 kHz |
Bit Depths | 24-Bit |
Stems Processing | via Dedicated Controls: Vocals/Acapella, Drums/Percussion, Bass, Other |
Connectivity
Audio Inputs | 1 x Stereo 2RCA Coaxial Aux Input 1 x Combo XLR-1/4" 3-Pin Balanced Mic Input 1 x 1/4" TRS Balanced Mic Input |
Audio Outputs | 2 x XLR 3-Pin Balanced Master Output 1 x Stereo 2RCA Coaxial Master Output 2 x 1/4" TRS Balanced Booth Output 1 x 1/4" TRS Headphone Output 1 x 1/8" / 3.5 mm TRS Headphone Output |
USB | 2 x USB-C (Host Connection) 1 x USB-C (Power Input) |
Wireless | None |
Media Card Slots | None |
Internal Drive Bays | None |
Performance
Frequency Response | 20 Hz to 20 kHz |
SNR | 110 dB |
THD | Line: 0.003% (USB) |
Compatibility
Included Software | Serato DJ Pro Serato Pitch 'n Time DJ |
OS Compatibility | macOS 11.2 to 13 Windows 10 to 11 *As of August, 2023: Check with manufacturer for the most up-to-date compatibility |
Mobile App Compatible | No *As of August, 2023: Check with manufacturer for the most up-to-date compatibility |
Processor Requirement | Intel Core i3 (64-Bit) Intel Core i5 (64-Bit) Intel Core i7 (64-Bit) Intel Core i9 (64-Bit) AMD (64-Bit) Apple M1 or Better |
RAM Requirements | 4 GB, 8 GB Recommended (64-Bit) |
Storage Requirements | 2 GB |
Minimum Display Resolution | 1280 x 720 |
Required Hardware | Available USB-C Port |
Internet Connection | Required for Registration, Software/Driver Download |
Power
Power Requirements | USB Bus Power |
Power Supply Output | 5 VDC at 3000 mA |
Physical
Dimensions (W x D x H) | 29.0 x 14.9 x 2.9" / 736.6 x 378.5 x 73.7 mm |
Weight | 13.67 lb / 6.2 kg |
