Apogee One USB Microphone and Music Interface for the Mac

Apogee One USB Microphone and Music Interface for the Mac

NE is a pocket-sized USB microphone and music interface featuring the award winning sound quality that made Apogee Electronics famous. Designed to work easily with Apple's GarageBand, Logic, Final Cut, or any Core Audio compliant application, ONE lets you create professional recordings anywhere.

With ONE, you can record a single channel of audio using the specially tuned enclosure microphone, an instrument input for guitar, bass, or keyboard, or a world-class microphone preamp input. Listening with ONE is an entirely new experience as well. Hear your recordings and your iTunes library with incredible dimension and clarity through ONE's studio-quality stereo output.

There's a Mic Inside:
Tuned Aperture Microphone™ Technology
Unlike any interface in its class, ONE features an internal reference condenser microphone that has been fine-tuned by professional recording engineers to create Apogee's Tuned Aperture Microphone™ technology. ONE with its tuned aperture microphone and fitted with the optional custom mic mount is the ultimate portable recording solution for quickly capturing musical ideas, recording high quality demos, rehearsals, podcasts, lectures, interviews, voice-overs and more.

Choose your Mic:

World-Class Mic Pre input
For those who prefer the sound of their favorite microphone, ONE features a worldclass microphone preamp with phantom power and a gain range of +10 to 63 dB. Based on the award winning mic preamps in Apogee's Ensemble and Duet, ONE's preamp is digitally controlled by the encoder knob. Level can also be set from within Apogee's Maestro, or your Mac's Sound and Audio MIDI Setup control panels.

Headphones or Speakers:

Studio Quality Stereo Output
Hear your recordings in their truest form and rediscover your iTunes library with ONE's studio quality stereo output. Controlled by the encoder knob, the output of ONE is supplied by the 1/8" jack on the front allowing connection to either headphones or powered speakers.

Guitar, Bass and Keyboards:

Instrument Input
Plug-in and play is made easy with ONE's instrument input. Perfect for guitar, bass, and keyboard, ONE's instrument input has extremely low noise and a transparent signal path making it the ideal solution for recording or performing live with your Mac.


Single channel input using one of the following three options:
Internal condenser microphone
Balanced XLR microphone preamp input with +10 to 63 dB of gain
Unbalanced 1/4” high impedance instrument input, 0 to 45 dB of gain
Software selectable 48V phantom power
Line-level, 1/8” stereo output for headphones or unbalanced powered monitors
A/D and D/A conversion @ 44.1/48kHz, 24-bit
Multi-function encoder knob for input gain control and output level control
4 encoder function LED indicators
3 segment LED input and output metering
Apogee’s Maestro software for advanced control and low latency mixing
Compatible with any Core Audio compliant audio application
Dimensions: 2.25" W x 4.75" L x 1" H

System Requirements

Computer: Mac, with an Intel or Power PC G5 processor
Memory: 1 GB minimum of installed RAM, 2 GB recommended
OS: 10.5.7 or greater
Connection and Power: USB, powered by any available USB port on the computer

Package Contents

Breakout Cable
USB Cable
Apogee Software & Documentation CD
QuickStart Guide
